IP BULLET CAMERAS

APTI250C228		5IN STOCK
Log in for prices

Product Details

Product Details Specification

APTI 2MP 2.8mm IP Camera (PoE) with Audio input, IR up to 30M

IP camera with efficient H.264 / H.265 image compression algorithm for clear and smooth video streaming at maximal resolution of 1080p.

Camera bracket allows to adjust the camera to any direction, and power cables are hidden inside the bracket. The range of IR illumination according to the manufacturer data, depends on outer conditions (visibility - air transparency, environment, wall colors ie. scene reflectance).

The compatibility of the camera with ONVIF standard ensures it can be used in different IP surveillance systems regardless of manufacturer. PoE powering possibility, compatible with the 802.3af standard makes the device more universal and easier to install.

Camera is has IP66 Index of Protection norm.

Optional extra: CAMMIC

Standard:

TCP/IP

Sensor:

1/2.8 " Sony CMOS IMX290, STARVIS Back-illuminated

Digital Image Processor:

Hisilicon 3516C

Matrix size:

2.1 Mpx

Resolution:

1920 x 1080 - 1080p

Operation modes:

The main and sub streams can only occur in the configurations shown:

Firmware 3516CV300_IMX290_TF_W_8.1.6.6

Main stream : 1920 x 1080 Sub stream : 720 x 480 352 x 288

Main stream : 1920 x 1080 Sub stream : 640 x 480 352 x 288

Lens:

2.8 ... 12 mm, 3 Mpx

View angle:

S/N ratio:

> 52 dB

Range of IR illumination:

60 m

IR illuminator power adjustment:

Automatic

Image compression method:

H.265 / H.265 / H.264 / H.264

Alarm inputs / outputs:

Audio:

External microphone input

Bitrate:

24 ... 9472 kbps - H.264

14 ... 5632 kbps - H.265

Main stream frame rate:

30 fps @ 1080p

Network interface:

10/100 Base-T (RJ-45)

Network protocols:

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP

Default IP address:

192.168.1.168

Default admin user / password:

admin / admin

Web browser access ports:

PC client access ports:

WEB Server:

Built-in

Mobile client access ports:

Max. number of on-line users:

Port ONVIF:

ONVIF:

2.4

RTSP.URL:

rtsp://user:password@ip_address:80/0 - Main stream

rtsp://user:password@ip_address:80/1 - Sub stream

Mobile phones support:

Port no.: 80 or access by a cloud (P2P)

Android: Free application FREEIP

iOS (iPhone): Free application FREEIP

RS-485 interface:

Main features:

3D-DNR - Digital Noise Reduction

WDR - Wide Dynamic Range

F-DNR (Defog) - Reduction of image noise caused by precipitation

ICR - Movable InfraRed filter

Possibility to change the resolution, quality and bit rate

Motion Detection

Privacy zones

Configurable: brightness, contrast, saturation

Sharpness - sharper image outlines

Mirror - Mirror image

RESET button - on the cable

Power supply:

PoE (802.3af),

12 V DC / 620 mA

Power consumption:

≤ 7.5 W

Housing:

Compact, Metal

Color:

White

"Index of Protection":

IP66

Supported languages:

English, Polish, Bulgarian, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Turkish, Italian

Operation temp:

-20 °C ... 60 °C

Weight:

1.02 kg

Dimensions:

288 x 90 x 103 mm
