Roofmount 6 non-invasive ballast mast with adjustable angle of the mast in relation to the ground is designed for the installation of satellite dishes.
• Base made of 3 mm thick extrusion-formed steel sheet with welded steel tube
• Designed for mounting satellite dishes
• Mast length: 1,1 m
• Mast diameter: 50 mm
• Base dimensions: 106,0 x 91,0 cm
• Mast tilt angle adjustment 0...5°
• Surface of elements protected by galvanised coating
Roofmount6 is a non-invasive ballast mast with adjustable angle of mast in relation to the ground is designed for the installation of satellite, television or data transmission antennas.
It enables installation on flat, resistant surfaces in places where interference in the structure or roof sheathing is impossible or inadvisable.
The ZB-1100/50 RAM6 ballast mast base, 1.1 m high and 50 mm in diameter, consists of 6 frames measuring 41.5 × 26.5 cm allowing the installation of 12 concrete blocks measuring: 38 cm × 24cm × 12 cm.
The satellite dish should be placed on the mast as low as possible, just above the concrete blocks.
The bracket is equipped with a mechanism enabling free adjustment of the pole's angle of inclination in relation to the ground 0...5°.
This allows the mast to be positioned vertically on surfaces with a slight slope, facilitating proper installation and ensuring the stability of the entire structure.
