3 Way Camera Switcher


Product Code: CAMSWITCH3
Log in to view prices

Product Details

Camswitch 3 allows you to select one to three video source signals input and connect it the output. The selection can be manual or automatic. For the automatic mode it is possible to change the inputs switching time from 0.5s to 125s with 0.5s step. The time setting can be done for all cameras together or for each camera independently. It is also possible to select inputs and bypass them in the sequence.

Manual and automatic switching.

  • Inputs switching time option
  • Selected inputs bypass option.
  • Settings saving to EPROM memory.

Number of inputs:

3

Number of outputs:

1

Inputs / outputs impedance:

75O

Power supply:

DC 12V / 50mA

Switching time range:

0.5s - 125s

Dimensions:

120 x 62 x 30 mm

Supplied complete with power supply
